DF060 - ultra compact force sensing module

Its STEMMA QT / Qwiic interface makes it a perfect fit for the maker community, as well as for rapid prototyping.

The DF060 Force Sensor Module is an easy-to-use force sensing solution designed for seamless integration into a wide range of applications.

At the heart of this ultra-compact module is the SMD-solderable strain gauge sensor PT061. This sensor is highly sensitive to mechanical deflection. The differential signal of the sensors integrated Wheatstone bridge is digitized by a high-resolution 24-bit ADC (NAU7802).

The DF060 module is easy-to-install and can be mounted either with screws or by using high-performance VHB adhesive tape.

There is a wide variety of applications for the DF060 module. Whether detecting a finger press through a metal surface or sensing the presence of a object, the module offers a flexible and robust force sensing solution.



Datasheet & Schematic







Product videos







Product Features

Ultra-compact & high sensitivity
PT061 strain gauge technology delivers exceptional sensitivity in an ultra-compact form factor.
Flexible mounting with screws or adhesive tape
Choose the installation method that best fits your application.
STEMMA QT / Qwiic compatible
Easy integration into your maker and professional projects.
High-resolution 24-bit ADC (NAU7802)
Exceptional precision with the 24-bit NAU7802 ADC, backed by a wide range of firmware libraries for rapid development.

Our agnostic force sensors

"Our agnostic force sensors offer maximum sensitivity and can also be assembled quickly and reliably as SMD components."
